Description:
Type: 3-speed full manual
Motor: DC motor
Driving Method :Belt drive
[Main Features]
Turntable Platter:330mm dia.
Aluminum diecast
Speeds:331/3 and 45 rpm and
78rpm
Pitch
Controls +/- 10%
Starting Time Less than 1 sec
with 331/3
Braking
Time
Less than 1 sec. with 331/3
Time for Speed
Change
Less than 1 sec. from 331/3 to
45 rpm.
Less than 1 sec. from 45 to
331/3 rpm.
Less than 1 sec. from 331/3 to
78 rpm
TONEARM SECTION:
Type
Static balanced S-shaped tonearm with detachable
headshell
Effective Arm Length
230.5mm
Tracking Error Angle
Less than 3 degree
Applicable Cartridge Weight
6~10g
Anti-skating Range
0-4g
Output
1.5~3.6mV at 1KHz 5cm/sec (HP-4005)
Frequency Response
20Hz-20KHz
Channel Separation
More than 15dB
Channel Balance
Within 2.5dB at 1KHz
Needle Pressure range
3~4g
High of cue(first track)
6~10.5mm
Descend of cue
1~3sec
[Specificatoins]
Power: AC 120V, 60Hz
consumption: 5.5 Watts Dimensions:449
(W) x 370 (D) x 145 (H) mm Weight: 4
Kgs Wow and Flutter:
Less than 0.2% WRMS (JIS WTD) with 331/3rpm S/N Ratio:
More than 60dB (DIN-B)
